Product Overview
Universal Column (UC), also called an “H-beam” for its square-ish cross-section, carries load on a vertical axis and resists twisting, used for major vertical support in steel-frame buildings, industrial and rural sheds.
Sizes follow the same designation format as UB: section depth in mm, followed by UC, followed by mass per metre in kg. For example, 200UC46.2 is a 200mm-deep column weighing 46.2kg per metre.
Grade: 300 (Grade 300+ steel, hot-rolled)
Standard: manufactured to AS/NZS 3679.1
Finish: standard mill (black steel)
Note: Non-standard sizes and lengths available on request; minimum order quantities (MOQs) apply
Products List
| Designation | Flange Width (mm) | Available Lengths | Mass (kg/m) |
|---|---|---|---|
| 100UC14.8 | 99.0 | 9000mm | 14.8 |
| 12000mm | 14.8 | ||
| 150UC23.4 | 152.00 | 12000mm | 23.4 |
| 150UC37.2 | 154.0 | Lineal Metre | 37.2 |
| 200UC46.2 | 203.00 | Lineal Metre | 46.2 |
| 12000mm | 46.2 |
DISCLAIMER
Product information, specifications and images are provided as a general guide only and may vary from those shown. Details and availability can change without notice. Please contact Budget Steel to confirm current stock, pricing and product specifications.
